Detail Thermal Oil Boiler
We are producing " THERMAL OIL BOILER"
Thermal Oil Boiler is High temperature heating systems, used for industrial processes - most often instead of steam, because of much higher operating temperatures at low operation pressures - and because of significant less overall operation costs. Steam requires pressure, whereas thermal oil can be pressureless up to 330 -340° C. Pressurised it can get up to 400° C.
The hot oil packages comprise heater, main pump, heat exchangers, expansion, dearating- and buffer tanks, emptying systems with pump and tank, special valves, strainers, compensators, safeties, controllers, auxiliary equipment, tubes, fittings, charge of thermal fluid and of course full documentation.
The simple principle in hot oil system is to heat up special thermal fluid by circulating the fluid through heaters ( with burners, electrical elements or flue gas recuperators) - and thereafter direct the fluid out to one or several consumers i.e. heat exchanger, air heaters, reactors, rollers etc.
Our Thermal Oil Boiler start from capacity 300.000 kcal/ hour with heating surface 4.2 M2 and are all tailor-made and they are always delivered as complete packages for assembly on site, or as skid mounted units when the size allows it and with full and easy accessible instruction for erecting, installation and maintenance.
We are also producing:
Spray Dryer
Vacuum Dryer
Rotary Dryer
Flash Dryer
Heat Exchanger
Fluidized Bed Dryer
Continuous Belt Dryer
Coal Gasifier
Fixed Bed Gasifier
Fluidized Bed Gasifier
Circulating Fluid Gasifier
Green Incinerator
Hi-Temp Incinerator
Plasma Incinerator
Coal Fuel Incinerator
Biofuel Equipments
Thermal Oil Boiler
Supercritical Fluid
Aerated Lightweight Concrete
For further info please contact:
Jon Maulana
PT. ARTECH
Jln Raya Narogong KM 9, 3 Bekasi
Tel: 021.8250033; 46444163
Hp: 0811.815750
Fax: 021.8211209
Email: sales@ artech.co.id
web: www.artech.co.id
